Mirror surface grinding
Machining requiring a fine surface finish
Application: Mold parts, Medical components, Semiconductor manufacturing equipment
MENU
| Items | Results | |
|---|---|---|
|
Workpiece |
Material | SKD11 |
| Hardness | HRC58 | |
| Size | W80×D80×H50 mm | |
|
Accuracy |
Surface roughness(Ra) | 0.0053 μm |
| Surface roughness(Rz) | 0.0354 μm | |
|
Machining time |
Finishing process | 60 min（Allowance 0.015 mm） |
|
Machine model used |
Machining equipment | GS-45Vs |
| Measuring equipment | FORM TALYSURF（Taylor Hobson） | |
Introduction to the Machining and Measurement Solution Room (Futtsu City, Chiba Prefecture)
- Our "Machining and Measurement Solution Room," located within our Futtsu factory, features operational machines on display.
- Test machining is available. Please share details such as workpiece size, shape, and target precision.
- Consultation booths in the room are available to discuss your problems, issues, and questions until you are satisfied with the results.
