Peripheral equipment for Surface Grinding Machines: Grind-All
Punch grinding device for Surface Grinding Machines
Supports grinding of punches with complex shapes.
A product designed to address the challenges of tool rooms when grinding complex-shaped punches. By attaching it to a surface grinder, it enables easy and highly precise grinding (±0.0025 mm) of various punch shapes up to 31.7 mm.
MENU
- Easy radius adjustment with the sliding V-block.
- Multi-surface machining is possible with the 24-division indexing device.
- Equipped with a sine mechanism, allowing for the setting of arbitrary angles.
- The main body is made of hardened tool steel and features an internal structure that prevents sludge intrusion, ensuring long-term durability.
- Delivers cost reduction and improved machining accuracy.
- In addition to punch grinding, it can be used for inspections, light grinding, jig hole drilling, jig alignment, indexing operations, dressing, and electrode machining.
