Peripheral equipment for Surface Grinding Machines: Jigs and Tools
A lineup including dial squares and master blocks.
We provide a variety of essential jigs and tools for manufacturing sites. For items not listed, please contact us.
MENU
- Capable of measuring perpendicularity.
- Dial gauge is optional.
- Main body perpendicularity within 0.0005 mm
- Main body is SKS-3 fully hardened (HRC60)
- JIS Grade 1 with ultra-precision lapped finish on all surfaces.
- Main body fully hardened with precision ground finish.
- Can be set at any position within the movable range, making it very convenient as an auxiliary tool for various jigs.
- Clamped with two screws each, allowing for easy and highly accurate fixation.
A measurement method where light is shone into a gap, and the amount of light leaking through is used to determine dimensions. Depending on skill level, readings can be taken in the range of 0.002–0.001 mm.
