Fine groove machining

  • Fine groove machining

High-precision fitting machining

Grooving machining using a formed grinding wheel, performed with either equal or unequal pitch.

Items Results

Workpiece

Material ELMAX
Hardness HRC58
Groove width 0.700 mm

Accuracy

Positioning accuracy 1 μm or less
Pitch error 0.6 μm or less

Machining time

Finishing process 480 min
(Allowance 2.500 mm× 20 pieces
0.500 mm×19 pieces)

Machine model used

Machining equipment GS-30Vs
Introduction to the Machining and Measurement Solution Room (Futtsu City, Chiba Prefecture)
  • Our "Machining and Measurement Solution Room," located within our Futtsu factory, features operational machines on display.
  • Test machining is available. Please share details such as workpiece size, shape, and target precision.
  • Consultation booths in the room are available to discuss your problems, issues, and questions until you are satisfied with the results.
